Restrained flange adaptor for PE pipe PN10/16
Restrained flange adaptor for ⟦Mpe⟧ pipes, compliant with EN545 standard.
Description
Product overview
The Restrained Flange Adaptor for ⟦Mpe⟧ Pipe PN10/16 is a specialized connection fitting designed specifically for polyethylene (⟦Mpe⟧) pipes. This adaptor provides a secure, leak-proof connection between ⟦Mpe⟧ pipes and flanged systems while maintaining the flexibility and durability characteristics of ⟦Mpe⟧ pipe systems.
Key Features
- ⟦Mpe⟧ Pipe Specific Design: Engineered specifically for polyethylene pipe connections
- Dual Pressure Rating: Suitable for both PN10 and PN16 pressure systems
- EPDM+Brass Sealing: Advanced sealing ring material for superior leak prevention
- Restrained Connection: Secure mechanical connection preventing pipe separation
- Wide Size Range: Available from DN50 to DN300
- Standard Compliance: Meets EN545 standard requirements
Technical Specifications
| Standard | EN545 |
| Coating Standard | EN30677 |
| Test Standard | EN12266-1 |
| Working Pressure | PN10/PN16 |
| Size Range | DN50 to DN300 |
| Connection Type | ⟦Mpe⟧ pipe |
| Suitable For | Potable water, neutral liquids, sewage |
| Sealing Ring Material | EPDM+Brass |
| Restraint System | EPDM+Brass sealing ring for secure ⟦Mpe⟧ pipe connection |
Material Components
The Restrained Flange Adaptor consists of 7 main components:
- Flange Body: Ductile iron construction for strength and durability
- ⟦Mpe⟧ Pipe Connection: Specialized fitting for polyethylene pipe
- EPDM+Brass Sealing Ring: Advanced sealing material for leak prevention
- Restraint Mechanism: Mechanical system to prevent pipe separation
- Bolt Holes: Standard flange bolt pattern for connection
- Gasket Seat: Precision machined surface for gasket sealing
- Protective Coating: EN30677 compliant coating for corrosion protection
Applications
- Water Distribution Systems: Municipal and industrial water supply networks
- ⟦Mpe⟧ Pipe Installations: Connection points in polyethylene pipe systems
- Pressure Systems: PN10 and PN16 pressure applications
- Utility Connections: Interface between ⟦Mpe⟧ pipes and flanged equipment
- Maintenance Points: Strategic locations for system maintenance and repair
Installation Notes
- Ensure ⟦Mpe⟧ pipe is properly prepared and cleaned before installation
- Follow manufacturer guidelines for proper sealing ring installation
- Use appropriate torque values for bolt tightening
- Verify pressure rating compatibility with system requirements
- Test connection integrity before system pressurization
Quality Assurance
All Restrained Flange Adaptors undergo rigorous testing according to EN12266-1 standards to ensure:
- Pressure integrity at rated working pressures
- Leak-tight performance under various conditions
- Mechanical strength and durability
- Compliance with international standards
Please refer to the dimensions table below for specific size and bolt configuration details.
Dimensions Table (MM)
Note: Please note dimensions may vary at our discretion. All measurements are in millimeters (MM).
Bolt Configuration Details
Standard Bolt Pattern: All sizes use M12x50 bolts with 4-bolt configuration for consistent installation and maintenance.
This restrained flange adaptor for PE pipe PN10/16 is purpose-built for polyethylene distribution mains and industrial PE lines requiring secure flange connections under pressure. Future Maker delivers EN545-compliant ductile iron construction with dedicated PE gripping technology for European B2B projects.
Utilities and contractors benefit from reduced installation time, defined pressure tolerance and export-ready documentation. Submit your line specification for quotation.
Frequently asked questions
Why use a dedicated PE restrained adaptor instead of a universal model?
PE-specific restraint profiles optimise grip on polyethylene OD and SDR combinations, improving axial security and installation confidence on PE mains.
What PN ratings does this PE adaptor support?
It is rated for PN10 and PN16 systems. Match the adaptor to your design pressure and temperature limits.
Do you support LATAM and European export orders?
Yes. Include destination, incoterms and required certifications when requesting your B2B quote.
Additional information
| Adaptor Type | Restrained Flange Adaptor |
|---|---|
| Standard | EN545 |
| Coating Standard | EN30677 |
| Test Standard | EN12266-1 |
| Working Pressure | PN10/PN16 |
| Size Range | DN50 to DN300 |
| Connection Type | PE pipe |
| Suitable For | Potable water, neutral liquids, sewage |
| Sealing Ring Material | EPDM+Brass |
| Restraint System | EPDM+Brass sealing ring for secure PE pipe connection |
